Buttons in Custom Control Don't Show.
Hi Folks:
Developing on XP Home, VS 2008 Pro, C++, WIN32, no MFC.
I have a dialog, "IDD_SPLASH_DIALOG", with a custom control
which will be either a login dialog or a logo. This post relates
to the custom control as a login dialog.
The resoruce editor is being used to lay out both the splash
and the login screens.
The controls in the login dialog don't display in the rectangle
that defines the custom control.
Some graphics, consisting of some blocks of color and lines of
text are being drawn over the login dialog, as I want. Then I
want to place the user name edit control and the password edit
control over these graphics.
But GetDlgItem(hdlg, CONTROL_ID) returns NULL for controls I
know are in the login dialog.
As stated, these are being layed out by the Resource Editor,
the splash dialog is the parent and the login is the child
The child dialog is started with this:
login_window_handle = CreateDialogParam(hinstance,
TEXT("IDD_USER_LOGIN"),
hwnd_parent,
NULL,
(LPARAM)dialog_parameter_ptr);
Because the login screen is a custom control, I defined
a class for it, and open a WndProc instead of a DlgProc.
The class definition has "cbWndExtra = DLGWINDOWEXTRA"
and the class name matches. If it didn't the WndProc wouldn't
be called.
The WndProc has
return DefDlgProc(hdlg, message, wparam, lparam);
as the last statement. Being a child dialog, in an app that
must respond to user input on a menu in another window, this
is a modeless dialog, as is it's parent.
DestroyWindow() replaces the EndDialog() calls. I'm not
making that mistake.
Using the Resoruce Editor shows "IDD_USER_LOGIN" does have
the controls defined that the dialog proc can't find.
This might be a hint. I'm drawing the dialog with GDI+
functions. When the dialog is running, nothing is drawn
until I drag part of the dialog off of the edge of the parent.
Then things seem to draw and be fine.
If I'm using GDI+, do I still service the WM_PAINT.
BeginPaint(hdlg, &ps); and EndPaint(hdlg, &ps); are
being called.
Here is the .RC file for those two dialogs. Any idea?
IDD_USER_LOGIN DIALOGEX 0, 0, 377, 173
STYLE DS_SETFONT | DS_CONTROL | WS_CHILD | WS_VISIBLE
CLASS "USER_LOGIN_CLASS"
FONT 8, "Arial", 400, 0, 0x0
BEGIN
EDITTEXT IDC_ADMINISTRATIVE_USER_NAME,291,7,79,15,ES_AUTOHSCROLL
EDITTEXT IDC_LOGIN_PASSWORD,291,25,79,15,ES_PASSWORD |
ES_AUTOHSCROLL
LTEXT "User Name",IDC_STATIC,228,7,46,15,SS_CENTERIMAGE
CTEXT "Caps
Lock",IDC_CAPS_LOCK_WARNING_STATIC,281,57,89,23,SS_CENTERIMAGE | NOT
WS_VISIBLE
LTEXT "Password",IDC_STATIC,228,26,46,15,SS_CENTERIMAGE
CONTROL "Show As Clear
Text",IDC_SHOW_PASS_PHRASE,"Button",BS_AUTOCHECKBOX | BS_PUSHLIKE |
BS_NOTIFY | WS_TABSTOP,177,62,90,15
PUSHBUTTON "Cancel",IDCANCEL,139,151,50,15,NOT WS_VISIBLE |
WS_DISABLED
DEFPUSHBUTTON "OK",IDOK,66,151,50,15,NOT WS_VISIBLE | WS_DISABLED
END
IDD_SPLASH_DIALOG DIALOGEX 0, 0, 670, 416
STYLE DS_SETFONT | DS_CONTROL | WS_CHILD | WS_VISIBLE
FONT 8, "Arial", 400, 0, 0x0
BEGIN
PUSHBUTTON "Cancel",IDCANCEL,239,395,50,14
CONTROL
"Custom1",IDC_LOGIN_CONTROL,"USER_LOGIN_CLASS",WS_TABSTOP,70,56,554,206
END
I hope this isn't a stupid mistake, but I don't make smart
mistakes.
Thanks
Larry
date: Thu, 12 Jun 2008 10:28:43 -0700
author: Larry Lindstrom
Re: Buttons in Custom Control Don't Show.
Larry Lindstrom wrote:
> Hi Folks:
>
> Developing on XP Home, VS 2008 Pro, C++, WIN32, no MFC.
>
> I have a dialog, "IDD_SPLASH_DIALOG", with a custom control
> which will be either a login dialog or a logo. This post relates
> to the custom control as a login dialog.
>
> The resoruce editor is being used to lay out both the splash
> and the login screens.
>
> The controls in the login dialog don't display in the rectangle
> that defines the custom control.
>
> Some graphics, consisting of some blocks of color and lines of
> text are being drawn over the login dialog, as I want. Then I
> want to place the user name edit control and the password edit
> control over these graphics.
>
> But GetDlgItem(hdlg, CONTROL_ID) returns NULL for controls I
> know are in the login dialog.
>
> As stated, these are being layed out by the Resource Editor,
> the splash dialog is the parent and the login is the child
>
> The child dialog is started with this:
>
> login_window_handle = CreateDialogParam(hinstance,
> TEXT("IDD_USER_LOGIN"),
> hwnd_parent,
> NULL,
> (LPARAM)dialog_parameter_ptr);
>
> Because the login screen is a custom control, I defined
> a class for it, and open a WndProc instead of a DlgProc.
>
> The class definition has "cbWndExtra = DLGWINDOWEXTRA"
> and the class name matches. If it didn't the WndProc wouldn't
> be called.
>
> The WndProc has
>
> return DefDlgProc(hdlg, message, wparam, lparam);
>
> as the last statement. Being a child dialog, in an app that
> must respond to user input on a menu in another window, this
> is a modeless dialog, as is it's parent.
>
> DestroyWindow() replaces the EndDialog() calls. I'm not
> making that mistake.
>
> Using the Resoruce Editor shows "IDD_USER_LOGIN" does have
> the controls defined that the dialog proc can't find.
>
> This might be a hint. I'm drawing the dialog with GDI+
> functions. When the dialog is running, nothing is drawn
> until I drag part of the dialog off of the edge of the parent.
> Then things seem to draw and be fine.
>
> If I'm using GDI+, do I still service the WM_PAINT.
>
> BeginPaint(hdlg, &ps); and EndPaint(hdlg, &ps); are
> being called.
>
>
> Here is the .RC file for those two dialogs. Any idea?
>
> IDD_USER_LOGIN DIALOGEX 0, 0, 377, 173
> STYLE DS_SETFONT | DS_CONTROL | WS_CHILD | WS_VISIBLE
> CLASS "USER_LOGIN_CLASS"
> FONT 8, "Arial", 400, 0, 0x0
> BEGIN
> EDITTEXT IDC_ADMINISTRATIVE_USER_NAME,291,7,79,15,ES_AUTOHSCROLL
> EDITTEXT IDC_LOGIN_PASSWORD,291,25,79,15,ES_PASSWORD |
> ES_AUTOHSCROLL
> LTEXT "User Name",IDC_STATIC,228,7,46,15,SS_CENTERIMAGE
> CTEXT "Caps
> Lock",IDC_CAPS_LOCK_WARNING_STATIC,281,57,89,23,SS_CENTERIMAGE | NOT
> WS_VISIBLE
> LTEXT "Password",IDC_STATIC,228,26,46,15,SS_CENTERIMAGE
> CONTROL "Show As Clear
> Text",IDC_SHOW_PASS_PHRASE,"Button",BS_AUTOCHECKBOX | BS_PUSHLIKE |
> BS_NOTIFY | WS_TABSTOP,177,62,90,15
> PUSHBUTTON "Cancel",IDCANCEL,139,151,50,15,NOT WS_VISIBLE |
> WS_DISABLED
> DEFPUSHBUTTON "OK",IDOK,66,151,50,15,NOT WS_VISIBLE | WS_DISABLED
> END
>
> IDD_SPLASH_DIALOG DIALOGEX 0, 0, 670, 416
> STYLE DS_SETFONT | DS_CONTROL | WS_CHILD | WS_VISIBLE
> FONT 8, "Arial", 400, 0, 0x0
> BEGIN
> PUSHBUTTON "Cancel",IDCANCEL,239,395,50,14
> CONTROL
> "Custom1",IDC_LOGIN_CONTROL,"USER_LOGIN_CLASS",WS_TABSTOP,70,56,554,206
> END
>
> I hope this isn't a stupid mistake, but I don't make smart
> mistakes.
>
> Thanks
> Larry
Referring to the code fragments above:
Does the call to CreateDialogParam() succeed or fail?
Is hwnd_parent a valid window handle? Is it the handle of your splash
dialog?
Is the result from CreateDialogParam() being used in the call to
GetDlgItem()?
Are you doing something to position your IDD_USER_LOGIN dialog somewhere
other than the upper-left corner of the (presumably) splash dialog?
Have you looked at the windows created by your application with Spy++?
I see that you are creating a control called IDC_LOGIN_CONTROL in your
splash dialog. Why are you doing that in addition to calling
CreateDialogParam() to create the log-in dialog? Perhaps the window (it
won't be a dialog) that is created by that control is in the Z order on
top of the log-in dialog that you create with CreateDialogParam().
--
Norm
To reply, change domain to an adult feline.
date: Thu, 12 Jun 2008 19:25:56 -0700
author: Norman Bullen
