date: Thu, 28 Feb 2008 21:10:38 +0600,
group: microsoft.public.word.oleinterop
back
Re: Retrieval of fields
Hi Ivan,
In simple terms, you can access all fields in a document via the StoryRanges collection. For example:
Sub ProcessFields()
Dim oRange As Range, oFld As Field
If ActiveDocument.Fields.Count > 0 Then
For Each oRange In ActiveDocument.StoryRanges
Do
For Each oFld In oRange.Fields
' Do stuff
Next oFld
Loop Until oRange Is Nothing
Next
End If
End Sub
StoryRange constants include:
wdCommentsStory, wdEndnotesStory, wdEvenPagesFooterStory, wdEvenPagesHeaderStory, wdFirstPageFooterStory, wdFirstPageHeaderStory,
wdFootnotesStory, wdMainTextStory, wdPrimaryFooterStory, wdPrimaryHeaderStory, and wdTextFrameStory.
Since you apparently already know how to access the Header & Footer area, all you need to do to retrieve fields from
TextBoxes/TextFrames located there is to add a test for any associated wdTextFrameStory objects.
Cheers
--
macropod
[MVP - Microsoft Word]
-------------------------
"Ivan A. Vasilyev" wrote in message news:OLAGVwheIHA.4056@TK2MSFTNGP06.phx.gbl...
> Hello, NG
>
> I use Word 2000 Interops for Word 2007 automation. Can't find proper way for retrieving fields from TextBoxes/TextFrames located
> in a Footer/Header of a document.
>
> Enumeration through StoryRanges of a document won't help...
>
> foreach (Range r in document.StoryRanges)
> {
> foreach (Field f in r.Fields)
> {
> // fields in Footer/Header are hit
>
> //BUT
> //fields in TextBoxes/TextFrames located in Footer/Header are NOT hit
> }
> }
>
> Do not know whether it matters, but I found that my DOCX has two header*.xml files in its package.
> Moreover, my fields which I look for are stored in header2.xml. May be header2.xml is not PRIMARY header, but
> Word has only wdPrimaryHeaderStory story type. So second header is not in any story. Wild guess, but who knows... :)
>
> Please help me find right direction.
> TIA
> Ivan
>
date: Fri, 29 Feb 2008 10:45:49 +1100
author: macropod lid
Re: Retrieval of fields
Hello.
> In simple terms, you can access all fields in a document via the
> StoryRanges collection. For example:
>
> Sub ProcessFields()
> Dim oRange As Range, oFld As Field
> If ActiveDocument.Fields.Count > 0 Then
> For Each oRange In ActiveDocument.StoryRanges
> Do
> For Each oFld In oRange.Fields
> ' Do stuff
> Next oFld
> Loop Until oRange Is Nothing
> Next
> End If
> End Sub
It's not clear for me what "If ActiveDocument.Fields.Count > 0" condition is
used for. AFAIK, ActiveDocument.Fields returns fields from MainStory only.
"Do ... Loop Until oRange Is Nothing" is infinite loop I guess. Not quite
sure of a role of the loop at all. But main idea is clear.
> StoryRange constants include:
> wdCommentsStory, wdEndnotesStory, wdEvenPagesFooterStory,
> wdEvenPagesHeaderStory, wdFirstPageFooterStory, wdFirstPageHeaderStory,
> wdFootnotesStory, wdMainTextStory, wdPrimaryFooterStory,
> wdPrimaryHeaderStory, and wdTextFrameStory.
>
> Since you apparently already know how to access the Header & Footer area,
> all you need to do to retrieve fields from TextBoxes/TextFrames located
> there is to add a test for any associated wdTextFrameStory objects.
Could you give an example, please. Do not know how to get textboxes
ASSOCIATED with particulare header/footer.
[PSEUDOCODE] document.StoryRanges.Item(wdTextFrameStory)
I guess, this is not the case, cause it does not work for me. I.e. it does
not return textbox located in header.
TIA
Ivan.
date: Fri, 29 Feb 2008 13:30:54 +0600
author: Ivan A. Vasilyev
Re: Retrieval of fields
Hi Ivan,
I don't know the answer to that - I turned off the Drawing Canvas the first
time I saw it. And, one of the problems with a number of the features that
have been added to more recent versions of work is that they have not be
made accessible through the Object model.
As this is not a very heavily trafficed newsgroup, I would suggest that you
start a new thread in the microsoft.public.word.vba.general newsgroup, where
it will get a wider audience and may be seen by someone who has already
worked out how to do it.
--
Hope this helps.
Please reply to the newsgroup unless you wish to avail yourself of my
services on a paid consulting basis.
Doug Robbins - Word MVP
"Ivan A. Vasilyev" wrote in message
news:evxy$zseIHA.536@TK2MSFTNGP06.phx.gbl...
> Hello, Doug.
>
> Thanks for the link. Looping through stories of the same type
> (.NextStoryRange) did the trick, but with one EXCEPTION.
> I managed to find all textboxes and fields located in that textboxes
> (through Shapes enumeration). But TextBoxes (Shapes) placed on CANVAS are
> still not hit.
>
> Is it possible to pull shapes placed on a canvas?
>
> TIA
> Ivan
>
> "Doug Robbins - Word MVP" ÓÏÏÂÝÉÌ/ÓÏÏÂÝÉÌÁ ×
> ÎÏ×ÏÓÔÑÈ ÓÌÅÄÕÀÝÅÅ: news:%23%23jzwDseIHA.1212@TK2MSFTNGP05.phx.gbl...
>> Take a look at the article "Using a macro to replace text where ever it
>> appears in a document including Headers, Footers, Textboxes, etc." at:
>>
>> http://www.word.mvps.org/FAQs/MacrosVBA/FindReplaceAllWithVBA.htm
>>
>> You may be running up against the situation where your code is only
>> acting upon the first story of each story type in the document. There is
>> code in that article that gets around that situation.
>> --
>> Hope this helps.
>>
>> Please reply to the newsgroup unless you wish to avail yourself of my
>> services on a paid consulting basis.
>>
>> Doug Robbins - Word MVP
>>
>> "Ivan A. Vasilyev" wrote in message
>> news:uwi2B1qeIHA.4476@TK2MSFTNGP06.phx.gbl...
>>> I've just narrowed down the problem to the following.
>>> My Stories enumeration code does not hit fields in TextBoxes (only)
>>> located in header/footer.
>>>
>>> the code is
>>>
>>> foreach (Range r in document.StoryRanges)
>>> {
>>> foreach (Field f in r.Fields)
>>> {
>>> // fields in Footer/Header are hit
>>>
>>> //BUT
>>> //fields in TextBoxes located in Footer/Header are NOT hit
>>> }
>>> }
>>>
>>> Is it possible to get all TextBoxes in a document? If true, i could
>>> search for fields there.
>>>
>>> TIA
>>> Ivan
>>>
>>
>>
>
>
date: Sun, 2 Mar 2008 10:25:16 +1000
author: Doug Robbins - Word MVP
Re: Retrieval of fields
Thank you, Doug.
"Doug Robbins - Word MVP" ÓÏÏÂÝÉÌ/ÓÏÏÂÝÉÌÁ ×
ÎÏ×ÏÓÔÑÈ ÓÌÅÄÕÀÝÅÅ: news:%23n1Bqv$eIHA.5208@TK2MSFTNGP04.phx.gbl...
> Hi Ivan,
>
> I don't know the answer to that - I turned off the Drawing Canvas the
> first time I saw it. And, one of the problems with a number of the
> features that have been added to more recent versions of work is that they
> have not be made accessible through the Object model.
>
> As this is not a very heavily trafficed newsgroup, I would suggest that
> you start a new thread in the microsoft.public.word.vba.general newsgroup,
> where it will get a wider audience and may be seen by someone who has
> already worked out how to do it.
>
> --
> Hope this helps.
>
> Please reply to the newsgroup unless you wish to avail yourself of my
> services on a paid consulting basis.
>
> Doug Robbins - Word MVP
>
> "Ivan A. Vasilyev" wrote in message
> news:evxy$zseIHA.536@TK2MSFTNGP06.phx.gbl...
>> Hello, Doug.
>>
>> Thanks for the link. Looping through stories of the same type
>> (.NextStoryRange) did the trick, but with one EXCEPTION.
>> I managed to find all textboxes and fields located in that textboxes
>> (through Shapes enumeration). But TextBoxes (Shapes) placed on CANVAS are
>> still not hit.
>>
>> Is it possible to pull shapes placed on a canvas?
>>
>> TIA
>> Ivan
>>
>> "Doug Robbins - Word MVP" ÓÏÏÂÝÉÌ/ÓÏÏÂÝÉÌÁ ×
>> ÎÏ×ÏÓÔÑÈ ÓÌÅÄÕÀÝÅÅ: news:%23%23jzwDseIHA.1212@TK2MSFTNGP05.phx.gbl...
>>> Take a look at the article "Using a macro to replace text where ever it
>>> appears in a document including Headers, Footers, Textboxes, etc." at:
>>>
>>> http://www.word.mvps.org/FAQs/MacrosVBA/FindReplaceAllWithVBA.htm
>>>
>>> You may be running up against the situation where your code is only
>>> acting upon the first story of each story type in the document. There
>>> is code in that article that gets around that situation.
>>> --
>>> Hope this helps.
>>>
>>> Please reply to the newsgroup unless you wish to avail yourself of my
>>> services on a paid consulting basis.
>>>
>>> Doug Robbins - Word MVP
>>>
>>> "Ivan A. Vasilyev" wrote in message
>>> news:uwi2B1qeIHA.4476@TK2MSFTNGP06.phx.gbl...
>>>> I've just narrowed down the problem to the following.
>>>> My Stories enumeration code does not hit fields in TextBoxes (only)
>>>> located in header/footer.
>>>>
>>>> the code is
>>>>
>>>> foreach (Range r in document.StoryRanges)
>>>> {
>>>> foreach (Field f in r.Fields)
>>>> {
>>>> // fields in Footer/Header are hit
>>>>
>>>> //BUT
>>>> //fields in TextBoxes located in Footer/Header are NOT hit
>>>> }
>>>> }
>>>>
>>>> Is it possible to get all TextBoxes in a document? If true, i could
>>>> search for fields there.
>>>>
>>>> TIA
>>>> Ivan
>>>>
>>>
>>>
>>
>>
>
>
date: Mon, 3 Mar 2008 18:47:48 +0600
author: Ivan A. Vasilyev
|
|
